2.5D 3D Curved polising machine

  • Model No.:CP1200C
  • Available Materials:glass, sapphire, optical glass, quartz, ceramics.

Description

The machine is designed for surface polishing of 2.5D, 3D glass, sapphire, optical glass, quartz, ceramics and other hard and brittle materials

Samples

Features

  • The machine adopts simple planetary grinding and polishing principle, the bottom plate can be driven independently, and the four upper plates can be rotated independently to achieve single-side polishing;
  • The upper plate vacuum adsorption workpiece, clamping and removal is very convenient to turned over both sides have 4 plates and the other side of the work can be loaded workpiece and continuous efficiently polish;
  • The sponge pad on the disc, and soft polishing materials such as brush and carpet can be used to reduce the vibration of the machine;
  • The motor adopts frequency conversion motor to achieve smooth stop, acceleration, deceleration and reversing operation;

Technical Parameters

Item(1200C)Parameters
Upper Polishing diskNumber8
SizeØ500(mm)
Rotation speed0~20RPM
Max Running550mm
Motor3pcs 200KW 1300RPM
Carrier DiskSizeØ1200(mm)
Max Running0~100RPM
Motor3pcs 11KW  1450RPM
Time Setting0~9999s
Sand Pump Power0.25KW
Air Pressure0.55~0.65Mpa
Capacity17KVA
Size2340×1630×1900(mm)
Weight2400kg
