Da4040

Cropper single diamond wire saw

  • Model No.:DA4040
  • Available Materials:Large size sapphire, silicon carbide
  • Max Cutting Size:400mm×400mm×400mm
  • Cutting Size:Straight flake
  • Running Speed:max 1200m/min
Categories: , , ,
Inquiry

Description

This series uses a single diamond wire to cut brittle hard materials such as sapphire and silicon carbide with a large size. It has the characteristics of high processing precision, fast routing speed and good stability.

Cutting Samples

Features

  • Underside workbench:upward movement more efficient with low kerf loss
  • Cutting Large size sapphire, silicon carbide
  • Low consumption
  • Less guides reduced to 5 pieces:easy winding
  • Diamond wire swing:great tension and more efficient cutting
  • Wire break memory system:high precision cutting
  • High speed:Max speed 1200m per min.
  • Simply&Convenient operation
  • Compact structure:One-piece Unit Structure

Technical Parameters

ItemDetailParameters
AbilityMax work size400mmX400mmX400mm
WireDiamond wire diameterΦ0.25mm-Φ0.37mm
Storage20km(Φ0.25mm)
Swing angle±15℃
Wire RunningRunning speedmax1200m/min
Repeat ratemax 12 times/min
Running directionBidirectional
WorkbenchHorizontal strokemax 400mm
Lift speed0.1-999.9mm/hour
Mortar&FluidStorage70L
Flow rate100L/min
Control DevicesSystemINOVANCE
Touch screen&PLC&Motion controller
Motor Power8 Servo Motor17.8 kW
Mortar Motor0.1kW
PowerPowerAC380V Three-phase four-wire system
Power consumption≤10 kW
Size&WeightSize1800mm×1800mm×1900mm
Weight1600kg
